Specification

Overall weight(kg)

2700

L×W×H(mm)

4700×1400×2470（2280）mm

Rated bucket capacity(m³)

0.5

Rated load(kg)

800-1000

Dump height (mm)

2350

Dump distance

700mm

Wheelbase

2100mm

Thread

1405mm

Total time

11s

Engine

Model

Changchai ZN390Q

Type

Direct injection, horizontal, water-cooled,four stroke, three cylinder

Rated power(KW)

25KW

Rated speed(r/min)

2400

Working system

Transmission System

Manual clutch or hydrostatic

Distribution of work valve

DF15.2C

Working pump

CBF32

Steering system

Type

Articulated hydraulic steering

Max. turning angle

35°±1

Min turning radius(mm)

3400

Tires

Standard tires

7.50-16

Optional tires

10-16.5 or 31*15.5-15 wider tire 28X9-15 tires, same as used on forklift
